What does M10x1 5 mean For example an M10x1 5 coarse thread has a 1 5mm pitch while an M10x1 25 fine thread has a 1 25mm pitch For example the thread The International Organization for Standardization ISO simplifies metric thread callouts for coarse threads by eliminating the pitch callout So a thread labeled M10 implies a coarse
Let s start with the M10 part The big M means that this is a metric thread The 10 is the nominal outside diameter of the thread In tech speak the major diameter In this case it would be 10mm The picture shows the major diameter of a thread The following table chart are standard metric internal thread sizes M 9 M 24 per ANSI ASME B1 13M 1995 These thread sizes and classes represent bolts and screws as well as other
