Gi Pipe Reducer Sizes The function of both types of reducer is to reduce the line from a larger to a smaller pipe size this obviously results in an increased flow pressure With the eccentric reducer the smaller outlet is off center to the larger inlet enabling it to line up with one side of the inlet and not with the other making it deal for horizontal piping
Reducers be applied to change from pipe diameter in one direction Standard there are 2 possibilities the concentric reducer and the eccentric reducer GI pipe price list for seamless and welded type including fittings For pipe installation man hours please check the link PIPE INSTALLATION MAN HOURS For fitting not listed below such as flanges you can use the price of the BLACK IRON PIPES AND FITTING The galvanization cost is usually 28 50 Php per kilogram
